Display
- 2.4'' 240x320 pixels color display
- Intuitive user interface with icons and softkeys
- Caller ID with name and number
- Notification Light: voice mail and missed call are signaled via the display and illuminated power indicator
- Date & time (manual/auto synchronization)
- Screen saver
- Multiple languages
- LCD backlight
- Keypad backlight
Phone Features
- Up to 2 simultaneous calls per handset
- Handset select for receiving a call
- Handset and Number select for making a call
- Auto intercom, auto answer
- Call hold
- Call transfer
- Swap between calls
- 3-way conference
- Call waiting, mute, DND
- Redialing of the last 20 numbers entered
- Call forward (Always/Busy/No Answer)
- Speed dial
- Voice mail
- Silence
- 100 phone book memory (store in the base)
- Remote phonebook
- Phonebook search, block list
- Call history (All/Placed/Missed/Received)
- Direct IP call without SIP proxy
- Reset to factory, reboot
- Keypad lock, emergency call
- Anonymous call
- Anonymous call rejection
Audio Features
- Full-duplex speakerphone
- Hearing Aid Compatibility (HAC) compliant
- Receiver volume control: 5 steps
- Ringer volume control: 5 steps+off
- 9 ringer melodies
- Multiple advisory tones
- Acoustic warning for low battery status
- DTMF
DECT
• Frequency bands: 1880 – 1900 MHz (Europe), 1920 – 1930 MHz (US) , 1900 – 1906 MHz (Thailand)
Connectors and Management
• Headset jack (3.5 mm)
• Handset upgrade: OTA (Over-The-Air)
Physical Features
- DECT Range:
- - Up to 50 meters indoors (in ideal conditions)
- - Up to 300 meters outdoors (in ideal conditions)
- Battery of W56H (V0-V3):
- - 1460 mAh, Lithium-ion, 3.7 V, 5.4 Wh
- - Up to 30 hours of talk time (in ideal conditions)
- - Up to 400 hours of standby time (in ideal conditions)
- Battery of W56H (V4):
- - 3 × 3.7 V 350 mAh (1.295 Wh), Lithium-ion
- - Up to 30 hours of talk time (in ideal conditions)
- - Up to 350 hours of standby time (in ideal conditions)
- 12-key numerical keypad
- 5 navigation keys
- 2 softkeys
- 6 function keys
- 6 shortcut keys
- Charger: DC 5 V/600 mA Output
- Maximum transmission power: 10 milliwatts
- Color: Alabaster Silver
- Phone size: 175 mm x 53 mm x 20.3 mm
- Operating humidity: 10-95%
- Operating temperature: 0 to +40°C (+32 to 104°F)
- Storage temperature: - 30 to +70°C (-22 to +158 °F)
Package Features
- Package contents:
- - W56H Handset
- - USB Charger Cradle
- - Rechargeable Lithium Battery
- - Belt Clip
- - Power Adapter
- Qty/CNT: 20 PCS
- Giftbox size: 200 mm x 104 mm x 90 mm
- Carton Meas: 51 mm x 443 mm x 198 mm
- N.W: 6.8 kg
- G.W: 7.7 kg
